HLG 350 Diablo

HLG 350 Diablo

SKU: HLG-350R-DIABLO
$549.00
Available to Order (23 available)
Inventory may be in-store or supplier warehouse. Call 419-725-2450 to confirm same-day pickup.
Questions? Call 419-725-2450

Quick answer

HLG 350 Diablo should be matched to canopy footprint, mounting height, dimming needs, crop stage, heat load, and controller compatibility.

Best fitGrow spaces where the fixture footprint, power draw, and hanging height fit the actual canopy.
Check before orderingConfirm voltage, plug type, controller compatibility, dimensions, hanging hardware, and room heat management.
Grower tipStart with conservative intensity, then raise output as plants respond. Airflow and distance matter as much as wattage.

Shopping guidance from Toledo Indoor Garden. Prices, availability, shipping rates, weights, and dimensions are verified during checkout.

Description

HLG 350 Diablo commercial lamps are designed to replace a 600 watt HID with just 330 Watts.

Each HLG 350 Diablo uses 2 of our custom designed Advanced Design Diablo Quantum Boards® with Full Spectrum White & Deep Red LEDs.

With its rectangular footprint and integrated reflectors, this fixture is ideal for flowering in smaller grow spaces or vegging in a commercial grow.

Integrated reflectors improve photon delivery resulting in higher quality yields even at the lower levels of the canopy.

This incredibly efficient full spectrum horticulture lamp has an efficiency of 2.80 PPF/W.

Download the HLG 350 Diablo MANUAL Independent Efficiency Lab Report Grow Flux Information Booklet An Access Point (sold separately) is required if you choose the Grow Flux wireless dimming option.

Top Features • 35" wide design for even light coverage • Powered with high efficiency Diablo™ Quantum Boards® for 2.80 PPF/W • 950+ PPF high output to replace even 600W HPS • Full spectrum white and 660nm red • Reliable passive-cooled design • Better canopy light penetration with diffused light • 0 to 330 Watts dimming design • Auto sensing Inventronics power supply works on 120VAC, 240VAC, and 277VAC • 5 Year Warranty Specifications Power 0-330 Watts Voltage Range 120-277 VAC 50-60Hz LED Full Spectrum White & Deep Red Flowering Footprint 3' x 5' at 15" Veg Footprint 4' x 5' at 24” System PPF Efficacy 2.80 μmol/joule Total output 950+ PPF Dimensions 35" x 9.5" x 3.25" Product Weight 10 lbs Recommended Mounting Height 15" - 24" above canopy Certifications UL 8800, UL 1598, CSA Independent PPFD Report* *Expect higher intensity and more even coverage in a grow tent, reflective area or a cross over with multiple lamps.

Watts to BTU Calculator, Cooling Requirement Calculator Conforms to ANSI/CAN/UL STD 8800, Conforms to UL STD 1598, Certified to CSA STD C22.2 # 250 Weight: 6.00 lbs.

Dimensions: 24 x 24 x 4 in.

Available sizes: 120V / 240V / RJ 0-10V with Manual Knob, 120V / 240V / Grow Flux.

  • LED
  • 600W wattage output
  • Genuine HLG product
  • Brand: HLG
  • Category: Grow Lights > LED Grow Lights
  • 2 selectable options

Specifications

SKUHLG-350R-DIABLO
BrandHLG
UPC
Weight6.00 lbs
Dimensions24 x 24 x 4 in
TypeLED
Wattage600W
PPF (Output)950+ µmol/s
PPE (Efficiency)2.80 µmol/J
SpectrumFull Spectrum
Input Voltage120-277 VAC, 50-60Hz
Coverage (Flower)3' x 5' at 15"
Coverage (Veg)4' x 5' at 24"
Mounting Height15-24" above canopy
LEDs2x Diablo Quantum Boards® with integrated reflectors
DriverAuto-sensing Inventronics (120/240/277V)
Dimming0-330W dimming
CoolingPassive
CertificationsUL 8800, UL 1598, CSA
Warranty5 Years
Efficacy2.80 µmol/J
Voltage120V
DimmableYes
ColorWhite
